300W 350W 600W 700W 800W 1200W 1400W 1600W Solar Inverter Grid Tie Mppt Micro Inverter, MPPT Micro Solar Inverter Waterproof Grid Tie Inverter Converter w/WiFi Mobile Phone Monitoring System,WVC-300W

▶【SPECIFICATIONS】Type: Grid-tied Micro InverterModel: WVC-300W, WVC-350W, WVC-600W, WVC-700W, WVC-800W, WVC-1200W, WVC-1400W, WVC-1600WMaterial: Aluminum alloy + PCB board + various componentsNumber of mc4 input connectors: 1-4 groups (300W 350W: 1 groups; 600W 700W 800W: 2 groups; 1200W 1400W 1600W: 4 groups)MPPT Max. Power Point Tracking Voltage Range: 30V - 54vOperating Voltage Range: 22 - 60VMinimum Start-up Voltage: 20vMax. Branch Input Voltage: 60VAC Output Voltage: 120V/230v (automatic identification)Max DC Input Power: 300W, 350W, 600W, 700W, 800W, 1200W, 1400W, 1600WOperating Temperature Range: -40°C to +65°CRated AC Frequency: 50hzMonitoring System: Mobile Phone APPOutput Power Factor:>0.99Total Harmonic Distortion Rate of Output Current: THD<5%Maximum Conversion Efficiency: 95%MPPT Tracking Efficiency: 99.9%Waterproof Class: IP65Cooling Method: Auto - cooling▶【ATTENTION】DC input limit - Input voltage range: 22v to 60v, solar panel: recommended power greater than 30w; Standard voltage 36V photovoltaic panels. It is recommended to use solar panels in parallel, because series connection may cause the input voltage to be too high and exceed the operating voltage range of the inverter.▶【PACKING LIST】1 x inverter1 x communication antenna2 x Set of fixing screws1 x AC output line1 x installation user manual▶【24H CUSTOMER SERVICE】If you have any questions, please contact us and we will reply you sooner.(within 24 hours). I wish you a happy life!

• ►【HIGH POWER POINT TRACKING (MPPT)】: Constant current, constant power - this product is constant current, constant power output, and will not appear overload or overcurrent phenomenon. The product's built-in MPPT (Max. Power Point Tracking) optimizes the energy collection of the solar panel and accurately captures and locks the maximum output power point to greatly increase the power generation to more than 25%.
• ►【WIDE VOLTAGE INPUT】: 1. Wide voltage input (22-60V DC) - realizes wide voltage input; 2. Secondary power transformation conversion; 3. Automatically turn off the output when the power grid is faulty - when the power grid fails, the inverter will automatically turn off the output; 4. The input and output are completely isolated, the electricity is safer, 120V and 230V output voltage automatically adapts.
• ►【APP INTELLIGENT MONITORING】: Using wireless communication system, with mobile phone APP monitoring, you can always know the operating status of the equipment, monitor AC voltage, AC frequency, AC current, real-time power generation, total power generation and other important parameters.
• ►【STACKED USE】: Simple and flexible installation, low operating and maintenance costs. In order to meet the requirements of higher power use, this product can be used in stacks, such as: 4 x 300W grid-connected inverters are used in stacks equal to 1200W, and the number of stacks is unlimited (solar panel: recommended power above 30W; photovoltaic panel standard voltage 36V).
• ►【IP65 WATERPROOF QUALITY】: which completely prevents raindrops from entering, and the aluminum alloy shell can effectively prevent rainwater from eroding the surface, has good corrosion resistance and oxidation resistance. (It is recommended to use a grid-connected microinverter to use solar panels in parallel, because the series connection will cause the input voltage to be too high and exceed the operating voltage range of the inverter.)
